Outdoor LED Display Screen with IP65 Waterproof 4000-5000 cd/m² Brightness and 3840-7680Hz Refresh Rate for Advertising and Events
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | LEDKING |
| Model Number: | Outdoor P2.9 P3.91 P4.81 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | $169-185 |
|
Detail Information |
|||
| Pixel Pitch: | 2.9mm, 3.91mm, 4.81mm | Brightness: | 4000-5000 Cd/m² |
|---|---|---|---|
| Color Depth: | 16-Bit | Color Temperature: | 2000K~10000K |
| Contrast Ratio: | 4000:1 | Operating Temperature: | -20℃~60℃ |
| Pixel Density: | 118906/65410/43222 Dot/㎡ | Power Consumption: | 600W/m² |
| Power Supply: | 110V-220V | Refresh Rate: | 3840-7680HZ |
| Resolution: | 172*172, 128*128, 104*104 | Viewing Angle: | 170° |
| Waterproof Rating: | IP65 | Cabinet Material: | Die-casting Aluminum |
| Module Size: | 250*250mm | ||
| Highlight: | IP65 Waterproof LED Video Wall,4000-5000 cd/m² Brightness LED Display Panel,3840-7680Hz Refresh Rate Outdoor LED Display Screen |
||
Product Description
Outdoor LED Display Panels - P2.9, P3.91, P4.81 Pixel Pitch
High-performance outdoor LED wall panels and cabinets designed for advertising, concerts, weddings, events, and stage displays. These rugged displays deliver exceptional visibility and reliability in various outdoor environments.
Technical Specifications
| Product Type | LED Display |
| Application | Outdoor |
| Pixel Pitch Options | 2.9mm, 3.91mm, 4.81mm |
| Pixel Density | 118,906 / 65,410 / 43,222 dots/m² |
| Resolution | 172×172, 128×128, 104×104 |
| Brightness | 4000-5000 cd/m² |
| Color Temperature | 2000K~10000K |
| Contrast Ratio | 4000:1 |
| Viewing Angle | 170° |
| Refresh Rate | 3840-7680Hz |
| Color Depth | 16-Bit |
| Scan Rate | 1/21S, 1/16S, 1/13S |
| Power Consumption | 600W/m² |
| Power Supply | 110V-220V |
| Operating Temperature | -20℃ to 60℃ |
| Waterproof Rating | IP65 |
| Sunlight Readable | Yes |
| Life Span | 100,000 Hours |
| Cabinet Material | Die-casting Aluminum |
| Cabinet Size | 500mm×500mm / 500mm×1000mm |
| Module Size | 250mm×250mm |
| IC Type | ICN2153 |
| Control System | Novastar System |
| Service Access | Front/Rear Service |
| Mounting Options | Wall Mount, Ceiling Mount, Custom Mount, Floor Stand |
| Warranty | 2 Years |
| Certifications | FCC, CE |
| Place of Origin | Guangdong, China |
Key Features
- High brightness (4000-5000 cd/m²) for excellent outdoor visibility
- IP65 waterproof rating for reliable outdoor operation
- Wide operating temperature range (-20℃ to 60℃)
- Professional Novastar control system with remote management
- Multiple pixel pitch options for different resolution requirements
- Die-casting aluminum cabinet for durability and heat dissipation
- Front and rear service access for easy maintenance
- Multiple mounting options for flexible installation
Applications
Outdoor advertising, retail stores, shopping malls, restaurant displays, hotel signage, airport information boards, commercial displays, rental events, marketing campaigns, exhibitions, street advertising, stage productions, and welcome displays.
Remote Management Capabilities
- Remote Content Management
- Real-Time Status Monitoring
- Remote Power Control
- Cloud-Based RDM Platform
- Third-Party CMS Compatible
Professional Support & Service
Shenzhen LED King Technology Co., Ltd. provides comprehensive professional support including one-to-one sales engineering, project consultation, installation guidance, and dedicated after-sales service teams available 24/7.
Frequently Asked Questions
What control system is used and how does it work?
We use Nova Taurus Series asynchronous control system that supports cluster play and management. The system is compatible with APP/Phone/WIFI/iPad/Laptop/PC/Cloud control, making it very easy and convenient to operate.
Can I order samples before placing a bulk order?
Yes, we welcome sample orders to test and check quality. Mixed samples are acceptable for evaluation purposes.
Is custom logo printing available?
Yes, we can print your logo on the product. Please inform us formally before production and confirm the design based on our sample.
What services do you provide?
- One-to-one sales engineer responsibility system
- Project consultation and optimal solution provision
- Order tracking with detailed progress updates
- Installation and usage guidance
- Comprehensive after-sales service support
What is your typical delivery time?
Generally, delivery takes 7-15 days after receiving your deposit. Specific delivery time depends on the items and quantity of your order.
What is your warranty policy?
We provide a 2-year warranty covering structure design, installation problems, system issues, and usage guidance. Our professional after-sale team will solve any questions after you place an order, and your exclusive sales engineer will help you overcome any problems.
Note: Most units feature Kinglight components and 3840Hz refresh rate. For custom pixel pitch requirements or technical modifications, please contact our team for detailed consultation.
