Outdoor P5 LED Video Wall with IP65 Waterproof Die-Cast Aluminum Cabinet and 1920Hz-3840Hz Refresh Rate
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | LEDKING or OEM & ODM |
| Model Number: | RO-P5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | $243-263 |
|
Detail Information |
|||
| Pixel Pitch: | 5mm | Pixel Density: | 40000 Dot/m2 |
|---|---|---|---|
| Pixel Configuration: | 1R1G1B | Max Power Consumption: | 25W |
| Panel Weight: | 0.25KG | Cabinet Size: | 960mm*960mm*90mm |
| Cabinet Resolution: | 192 Dot * 192 Dot | Quantity Of Panel: | 36pcs |
| Hub Connecting: | HUB75-E | Best Viewing Angle: | 170/120 |
| Screen Power Supply: | AC110V/220V - 5V60A | Max Power Capacity: | 1350W/m2 |
| Refresh Frequency: | 1920-3840 HZ/S | Brightness: | 5000-5500 Mcd/m2 |
| Operating Temperature: | -10C°~45C° | ||
| Highlight: | IP65 Waterproof LED Video Wall,Die-Cast Aluminum Cabinet LED Video Wall,1920Hz-3840Hz Refresh Rate LED Video Wall |
||
Product Description
Outdoor P5 960×960mm Die-Casting Aluminum Rental LED Display Panel
Product Specifications
Module Specifications
| Parameter | Outdoor P4.81 | Outdoor P5 | Outdoor P5 |
|---|---|---|---|
| Panel Dimension | 250mm(W) × 250mm(H) | 160mm(W) × 160mm(H) | 320mm(W) × 160mm(H) |
| Pixel Pitch | 4.81mm | 5mm | 5mm |
| Pixel Density | 43,264 dot/m² | 40,000 dot/m² | 40,000 dot/m² |
| Pixel Configuration | 1R1G1B | 1R1G1B | 1R1G1B |
| Specification | SMD2727/SMD1921 | SMD2727 | SMD1921 |
| Pixel Resolution | 52 dot × 52 dot | 64 dot × 32 dot | 64 dot × 32 dot |
| Max Power Consumption | 40W | 25W | 40W |
| Panel Weight | 0.65KG | 0.25KG | 0.45KG |
Cabinet Specifications
| Parameter | Outdoor P4.81 | Outdoor P5 | Outdoor P5 |
|---|---|---|---|
| Cabinet Size | 500×1000×90mm, 500×500×90mm | 960×960×90mm | 960×960×90mm |
| Cabinet Resolution | 104×208 dot, 104×104 dot | 192×192 dot | 192×192 dot |
| Quantity of Panels | 8pcs, 4pcs | 36pcs | 18pcs |
| Hub Connecting | HUB75-E | HUB75-E | HUB75-E |
| Cabinet Material | Die-casting aluminum | Simple Iron/waterproof iron | Die-casting aluminum |
| Maintenance Method | Front/Back service | Front/Back service | Front/Back service |
| Best Viewing Angle | 170°/120° | 170°/120° | 170°/120° |
| Screen Power Supply | AC110V/220V - 5V60A | AC110V/220V - 5V60A | AC110V/220V - 5V60A |
| Max Power Capacity | 1200 W/m² | 1350 W/m² | 976 W/m² |
| Average Power | 600 W/m² | 675 W/m² | 488 W/m² |
Technical Specifications
| Parameter | Outdoor P4.81 | Outdoor P5 | Outdoor P5 |
|---|---|---|---|
| Driving IC | ICN 2037 / 2153 | ICN 2037 / 2153 | ICN 2037 / 2153 |
| Scan Rate | 1/13S | 1/8S | 1/8S |
| Refresh Frequency | 1920-3840 Hz/s | 1920-3840 Hz/s | 1920-3840 Hz/s |
| Display Color | 4096×4096×4096 | 4096×4096×4096 | 4096×4096×4096 |
| Brightness | 3800-4000 cd/m² | 5000-5500 mcd/m² | 5000-5500 mcd/m² |
| Life Span | 100,000 Hours | 100,000 Hours | 100,000 Hours |
| Control Distance | < 100M | < 100M | < 100M |
| Best Viewing Distance | 4-40M | 5-40M | 5-40M |
| Operating Temperature | -10°C to 45°C | -10°C to 45°C | -10°C to 45°C |
| Operating Humidity | 10-90% | 10-90% | 10-90% |
| IP Protective Index | IP65 | IP65 | IP65 |
Most units feature Kinglight components and 3840Hz refresh rate. For alternative specifications, additional pixel pitch options, or detailed technical requirements, please contact our sales team.
