Outdoor P10 LED Video Wall with IP65 Waterproof 960*960mm Cabinet Size and 1920Hz-3840Hz Refresh Rate for Events
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | LEDKING or OEM & ODM |
| Model Number: | RO-P10 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | $345-365 |
|
Detail Information |
|||
| Pixel Pitch: | 10mm | Pixel Density: | 10000 Dot/m2 |
|---|---|---|---|
| Pixel Configuration: | 1R1G1B | Max Power Consumption: | 45W |
| Panel Weight: | 0.55KG | Cabinet Size: | 960mm*960mm*90mm |
| Cabinet Resolution: | 96 Dot * 96 Dot | Screen Power Supply: | AC220V - 5V60A |
| Max Power Capacity: | 1300W/m2 | Average Power: | 650W/m2 |
| Refresh Frequency: | 1920 HZ/S | Brightness: | 5000 Mcd/m2 |
| Best Viewing Distance: | 10-50M | Operating Temperature: | -10C°~45C° |
| IP Protective Index: | IP65 | ||
| Highlight: | IP65 Waterproof LED Video Wall,960*960mm Cabinet Size Outdoor LED Screen,1920Hz-3840Hz Refresh Rate Outdoor LED Display Screen |
||
Product Description
Outdoor P10 LED Display - Aluminum Cabinet Rental Solution
Professional outdoor LED wall display featuring 960×960mm aluminum cabinet construction, designed for exterior wall mounting and event applications with superior weather resistance.
Technical Specifications
Module Specifications
| Parameter | Outdoor P8 | Outdoor P8 | Outdoor P10 |
|---|---|---|---|
| Panel Dimension | 256mm(W) × 128mm(H) | 320mm(W) × 160mm(H) | 320mm(W) × 160mm(H) |
| Pixel Pitch | 8mm | 8mm | 10mm |
| Pixel Density | 15625 dot/m² | 15625 dot/m² | 10000 dot/m² |
| Pixel Configuration | 1R1G1B | 1R1G1B | 1R1G1B |
| Specification | SMD3535 | SMD3535 | SMD3535 |
| Pixel Resolution | 32 dot × 16 dot | 40 dot × 20 dot | 32 dot × 16 dot |
| Max Power Consumption | 28W | 40W | 45W |
| Panel Weight | 0.3KG | 0.5KG | 0.55KG |
Cabinet Specifications
| Parameter | Outdoor P8 | Outdoor P8 | Outdoor P10 |
|---|---|---|---|
| Cabinet Size | 768mm×1280mm×140mm, back service | 960mm×960mm×90mm | 960mm×960mm×90mm |
| Cabinet Resolution | 96dot × 160 dot | 120dot × 120 dot | 96 dot × 96 dot |
| Quantity of Panel | 30pcs | 18pcs | 18pcs |
| Hub Connecting | HUB75-E | HUB75-E | HUB75-E |
| Cabinet Material | Simple iron / waterproof iron cabinet | Die-casting aluminum cabinet | Die-casting aluminum cabinet |
| Maintenance Method | Front/Back service | Front/Back service | Front/Back service |
| Best Viewing Angle | 140°/120° | 140°/120° | 140°/120° |
| Screen Power Supply | AC110V/220V - 5V40A | AC110V/220V - 5V60A | AC220V - 5V60A |
| Max Power Capacity | 1020W/m² | 976W/m² | 1300W/m² |
| Average Power | 510W/m² | 488W/m² | 650W/m² |
Technical Signal Index
| Parameter | Outdoor P8 | Outdoor P8 | Outdoor P10 |
|---|---|---|---|
| Driving IC | ICN 2037 / 2153 | ICN 2037 / 2153 | ICN 2037 |
| Scan Rate | 1/4S | 1/5S | 1/2S |
| Refresh Frequency | 1920-3840 HZ/S | 1920-3840 HZ/S | 1920 HZ/S |
| Display Color | 4096×4096×4096 | 4096×4096×4096 | 4096×4096×4096 |
| Brightness | 5000mcd/m² | 4800mcd/m² | 5000 mcd/m² |
| Life Span | 100000 Hours | 100000 Hours | 100000 Hours |
| Control Distance | < 100M | < 100M | < 100M |
| Best Viewing Distance | 8-50M | 8-50M | 10-50M |
| Operating Temperature | -10°C to 45°C | -10°C to 45°C | -10°C to 45°C |
| Operating Humidity | 10-90% | 10-90% | 10-90% |
| IP Protective Index | IP65 | IP65 | IP65 |
Most models feature Kinglight components and 3840Hz refresh rate. For alternative specifications, additional pixel pitch options, and detailed technical requirements, please contact our technical team.
Manufacturing Excellence
Our company specializes in high-performance LED display solutions with rigorous quality control and innovative engineering for reliable outdoor applications.
