LEDKING P1.86 Indoor Theater LED Display Video Wall Home Cinema LED Screen Indoor LED Video Wall for Meeting Room Church
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | LED King |
| Certification: | CE FCC ISO |
| Model Number: | Indoor P1.86 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | $220/pc |
| Packaging Details: | Wooden case |
| Delivery Time: | 15days |
| Payment Terms: | T/T |
| Supply Ability: | According to your needs |
|
Detail Information |
|||
| Control System: | NOVA Star | Cabinet Material: | Die-casting Aluminium |
|---|---|---|---|
| Cabinet Size: | 640*480mm | Module Size: | 320*160mm |
| Scan Rate: | 1/43S | Life Span: | 100000Hours |
| Highlight: | P1.86 indoor LED display,theater LED video wall,meeting room LED screen |
||
Product Description
LEDKING P1.86 Indoor Theater LED Display
High-resolution video wall solution for home cinema, meeting rooms, churches, and other indoor applications featuring seamless splicing and true color reproduction.
Technical Specifications
Module Specifications
| Module Size | 320mm(W)*160mm(H) |
|---|---|
| Pixel Pitch | 1.86 mm |
| Pixel Density | 359856 dot/㎡ |
| Pixel Configuration | 1R1G1B |
| LED Specification | SMD1515 |
| Pixel Resolution | 172 dot*86 dot |
| Max Power Consumption | 30W |
| Panel Weight | 0.3KG |
Cabinet Specifications
| Cabinet Size | 640mm*480mm |
|---|---|
| Cabinet Resolution | 344 dot * 258 dot |
| Quantity of Panel | 6pcs |
| Hub Connecting | HUB75-E |
| Material | Die-casting aluminum cabinet |
| Maintenance Method | Front/Back service |
| Best Viewing Angle | 170/120° |
| Power Supply | AC110V/220V-5V40A |
| Max Power Consumption | 976W/㎡ |
| Average power consumption | 488W/m² |
Technical Signal Index
| Driving IC | ICN1065 |
|---|---|
| Scan Rate | 1/43S |
| Refresh Frequency | 3840-7680HZ/S |
| Display Color | 4096*4096*4096(16bit) |
| Contrast Ratio | 4000:1 |
| Brightness | 600-800 cd/㎡ |
| Life Span | 100000Hours |
| Best Viewing Distance | 1-30M |
| Operating Temperature | -10℃~60℃ |
| Operating Humidity | 10-70% |
| IP Protective Index | IP43 |
Core Features and Advantages
- Extremely detailed picture with high pixel density ensures sharpness and clarity even at close range
- Truly seamless splicing maintains image integrity and continuity
- True color reproduction with high color saturation, refresh rate, and grayscale levels
- Stable, energy-efficient design with flexible installation options
- Front/back maintenance capability for space-saving solutions
Application Scenarios
- Command and Control Centers: 24/7 operation for public security, traffic, emergency response, and military applications
- Broadcast and Television Studios: Background screens for news, variety shows, and weather forecasts
- High-End Conference and Auditoriums: Replacement for traditional projectors in boardrooms and video conferencing
- Commercial Display and Brand Spaces: Corporate showrooms, retail stores, museums, and tech exhibitions
Certification
CE
FCC
ISO
Packaging
Case Example
Want to Know more details about this product
