Outdoor LED Display Screen IP65 Waterproof with 4500-5500cd/m² Brightness and 3840-7680Hz Refresh Rate
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | LEDKING |
| Model Number: | Outdoor P5 P6 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | $426-443 |
|
Detail Information |
|||
| Brightness: | 4500-5500cd/m² | Color Depth: | 16-Bit |
|---|---|---|---|
| Color Temperature: | 2000K~10000K | Contrast Ratio: | 4000:1 |
| Operating Temperature: | -10C°~45C° | Resolution: | 192 Dot*192 Dot, 160 Dot*160 Dot |
| Waterproof Rating: | IP65 | Viewing Angle: | 170° |
| Refresh Rate: | 3840-7680HZ | Power Supply: | 110V-220V |
| Pixel Density: | 40000 Dot/㎡ / 27777 Dot/m² | Cabinet Size: | 960mm*960mm |
| Scan Rate: | 1/8S | Life Span: | 100000Hours |
| LED Specification: | SMD 1921 SMD3535 | ||
| Highlight: | IP65 Waterproof Outdoor LED Display Screen,4500-5500cd/m² Brightness LED Video Wall,3840-7680Hz Refresh Rate Digital Billboard |
||
Product Description
LEDKING Outdoor P5 P6 Waterproof LED Display Screen
High brightness outdoor advertising LED display designed for shopping centers, commercial spaces, and outdoor advertising applications.
Technical Specifications
| Model Number | Outdoor P5 P6 |
| Pixel Pitch | 5mm, 6mm |
| Pixel Density | 40,000 dot/㎡ (P5), 27,777 dot/m² (P6) |
| Brightness | 4500-5500 cd/m² |
| Resolution | 192×192 dot, 160×160 dot |
| Refresh Rate | 3840-7680 Hz |
| Color Depth | 16-Bit |
| Contrast Ratio | 4000:1 |
| Viewing Angle | 170° |
| Color Temperature | 2000K~10000K |
| Waterproof Rating | IP65 |
| Operating Temperature | -10°C to 45°C |
| Cabinet Size | 960mm × 960mm |
| Cabinet Material | Waterproof Iron |
| Power Supply | 110V-220V |
| Control System | Novastar System |
| LED Specification | SMD 1921 SMD3535 |
| Pixel Configuration | 1R1G1B |
| Scan Rate | 1/8S |
| IC | ICN2153 |
| Service Access | Front/Rear Service |
| Life Span | 100,000 Hours |
| Warranty | 2 Years |
| Certifications | FCC, CE |
Key Features
- High brightness (4500-5500 cd/m²) for excellent sunlight readability
- IP65 waterproof rating for reliable outdoor operation
- Wide 170° viewing angle for maximum visibility
- High refresh rate (3840-7680 Hz) for smooth video playback
- 16-bit color depth for vibrant, true-to-life colors
- Remote content management and real-time status monitoring
- Third-party CMS compatible for flexible integration
- Cloud-based remote device management platform
- Custom mounting options available
- Front and rear service access for easy maintenance
Applications
Outdoor advertising, shopping malls, retail stores, commercial displays, exhibitions, airports, hotels, restaurants, stage events, street advertising, marketing campaigns, and rental applications.
Company Profile
Shenzhen LED King Technology Co., Ltd. is founded by a professional team with extensive experience in LED display technology. Contact our service team for detailed discussions about your project requirements.
Professional Support
Most units feature Kinglight LEDs and 3840Hz refresh rate. For custom pixel pitch requirements and technical details, please contact our team for personalized solutions.
Frequently Asked Questions
What control system is used and how does it work?
We use Nova Taurus Series asynchronous control system that supports cluster play and management. Compatible with APP/Phone/WIFI/iPad/Laptop/PC/Cloud control for easy and convenient operation.
Can I place a sample order for the LED screen?
Yes, we welcome sample orders to test and check quality. Mixed samples are acceptable.
Is logo printing available on the product?
Yes, please inform us formally before production and confirm the design based on our sample.
What is your service approach?
- One-to-one sales engineer responsibility system
- Project analysis and optimal solution provision
- Complete order tracking with detailed updates
- Installation and usage guidance
- Comprehensive after-sales service support
What is your delivery time?
Generally 7-15 days after receiving deposit. Specific timing depends on items and order quantity.
What is your warranty policy?
2-year warranty covering structure design, installation problems, system issues, and usage guidance. Our professional after-sales team solves any questions after order placement.
