Outdoor LED Display Screen with IP65 Waterproof 4500-5500cd/m² Brightness and 3840-7680Hz Refresh Rate for Digital Billboard
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | LEDKING |
| Model Number: | Outdoor P5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | CN¥2,383.56-2,520.55 |
|
Detail Information |
|||
| Pixel Pitch: | 5mm | Brightness: | 4500-5500cd/m² |
|---|---|---|---|
| Color Depth: | 16-Bit | Color Temperature: | 2000K~10000K |
| Contrast Ratio: | 4000:1 | Refresh Rate: | 3840-7680HZ |
| Viewing Angle: | 170° | Waterproof Rating: | IP65 |
| Operating Temperature: | -10C°~45C° | Power Supply: | 110V-220V |
| Pixel Density: | 40000 Dot/㎡ | Resolution: | 192 Dot*192 Dot |
| Cabinet Size: | 960mm*960mm | Cabinet Material: | Waterproof Iron |
| Life Span: | 100000Hours | ||
| Highlight: | IP65 Waterproof Outdoor LED Display Screen,4500-5500cd/m² Brightness LED Video Wall,3840-7680Hz Refresh Rate Digital Billboard |
||
Product Description
Outdoor P5 Full Color LED Display
High-performance P5 outdoor LED display screen designed for vibrant digital signage and advertising applications. Features excellent waterproof protection and superior visibility in various outdoor environments.
Technical Specifications
| Model Number | Outdoor P5 |
| Pixel Pitch | 5mm |
| Pixel Density | 40,000 dots/㎡ |
| Resolution per Panel | 192 × 192 dots |
| Brightness | 4500-5500 cd/m² |
| Color Temperature | 2000K~10000K |
| Viewing Angle | 170° |
| Contrast Ratio | 4000:1 |
| Color Depth | 16-Bit |
| Refresh Rate | 3840-7680 Hz |
| Scan Rate | 1/8S |
| LED Specification | SMD 1921 |
| Pixel Configuration | 1R1G1B |
| IC Type | ICN2153 |
| Cabinet Size | 960mm × 960mm |
| Cabinet Material | Waterproof Iron |
| Waterproof Rating | IP65 |
| Operating Temperature | -10°C to 45°C |
| Power Supply | 110V-220V |
| Service Access | Front/Rear Service |
| Mounting Options | Custom Mount |
| Life Span | 100,000 Hours |
| Warranty | 2 Years |
| Certifications | FCC, CE |
| Control System | Novastar System |
Key Features
- High brightness (4500-5500 cd/m²) for excellent sunlight readability
- IP65 waterproof rating for reliable outdoor operation
- Wide 170° viewing angle for maximum visibility
- High refresh rate (3840-7680Hz) for smooth video playback
- Remote device management with real-time status monitoring
- Third-party CMS compatible for flexible content management
- Cloud-based remote management platform
- Durable waterproof iron cabinet construction
Applications
Ideal for outdoor advertising, retail stores, shopping malls, hotel displays, airports, commercial centers, rental events, marketing campaigns, restaurants, exhibitions, street signage, and stage productions.
Control & Management
Advanced remote device management system featuring remote content management, real-time status monitoring, remote power control, and cloud-based RDM platform. Compatible with third-party content management systems.
Manufacturer Profile
Shenzhen LED King Technology Co., Ltd. is a professional LED display manufacturer founded by an experienced team specializing in high-quality LED solutions.
Professional Support: Most units feature Kinglight LEDs and 3840Hz refresh rate. For custom pixel pitch requirements and technical details, please contact our engineering team.
Frequently Asked Questions
What control system is used and how does it work?
We use Nova Taurus Series asynchronous control system that supports cluster play and management. Compatible with APP/Phone/WIFI/iPad/Laptop/PC/Cloud control for easy and convenient operation.
Can I order samples before bulk purchase?
Yes, we welcome sample orders to test and verify quality. Mixed samples are acceptable for evaluation.
Is custom logo printing available?
Yes, we can print your logo. Please inform us before production and confirm the design based on our sample.
What services do you provide?
- One-to-one sales engineer customer responsibility system
- Project analysis and optimal solution provision
- Order tracking with detailed progress updates
- Installation and usage guidance
- Comprehensive after-sales service support
What is your delivery time?
Typically 7-15 days after receiving deposit. Exact delivery time depends on order items and quantity.
What is your warranty policy?
2-year comprehensive warranty covering structure design, installation issues, system problems, and usage guidance. Our professional after-sales team provides continuous support.
