High Brightness 4500-6500nit Outdoor LED Display with 7680Hz Refresh Rate and Customized Panel Size
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | LED KING |
| Model Number: | Outdoor P6 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 |
|---|---|
| Price: | $410 |
|
Detail Information |
|||
| Pixel Pitch: | 6mm | Pixel Density: | 167dot*167dot |
|---|---|---|---|
| Refresh Rate: | 7680Hz | Input Signal: | DVI, VGA, Etc. |
| Brightness: | 4500-6500nit | Panel Size: | Customized |
| Led Module Size: | 250 X 250mm | Led Panel Size: | 500 X 500mm / 500x1000mm |
| Led Panel Weight: | 7.3KG/13KG | Drive Method: | 1/32 Scan, 1/28 Scan, 1/16 Scan |
| Power Supply: | Chuanglian/ G-energy/ MeanWell | Receiving Card: | Novastar / Linsn / Colorlight / Huidu |
| Max Power Consumption: | 200W/pcs | Working Temperature: | -20℃~+50℃ |
| Best Viewing Distance: | 2-25m, 2.5-30m, 3-40m, 3-8m | ||
| Highlight: | 7680Hz Refresh Rate LED Video Wall,4500-6500nit Brightness Outdoor LED Display,Customized Panel Size Digital Billboard |
||
Product Description
P6 P8 P10 Indoor Outdoor Large Giant Advertising Animation Media Facade Curve Video Wall 3D LED Screen
High-performance LED display solutions for indoor and outdoor advertising, media facades, and curved video wall applications.
Technical Specifications
| Parameter | 2.6mm | 2.976mm | 3.91mm | 4.81mm |
|---|---|---|---|---|
| Pixel Pitch | 2.6mm | 2.976mm | 3.91mm | 4.81mm |
| LED Module Size | 250 x 250mm | 250 x 250mm | 250 x 250mm | 250 x 250mm |
| LED Panel Size | 500 x 500mm | 500 x 500mm | 500 x 500mm / 500x1000mm | 500 x 500mm |
| LED Panel Weight | 7.3KG | 7.3KG | 7.3KG/13KG | 7.3KG |
| Refresh Rate | 3840Hz | 3840Hz | 3840Hz | 3840Hz |
| Drive Method | 1/32 Scan | 1/28 Scan | 1/16 Scan | 1/16 Scan |
| Brightness | 1000nits | 1000nits | 1200nits | 1200nits |
| Power Supply | Chuanglian/ G-energy/ MeanWell | Chuanglian/ G-energy/ MeanWell | Chuanglian/ G-energy/ MeanWell | Chuanglian/ G-energy/ MeanWell |
| Receiving Card | Novastar / Linsn / Colorlight / Huidu | Novastar / Linsn / Colorlight / Huidu | Novastar / Linsn / Colorlight / Huidu | Novastar / Linsn / Colorlight / Huidu |
| Max Power Consumption | 200W/pcs | 200W/pcs | 200W/pcs | 200W/pcs |
| Working Temperature | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ | -20℃~+50℃ |
| Best Viewing Distance | 2-25m | 2.5-30m | 3-40m | 3-8m |
| Best Viewing Angle | H: 140°; V:140° | H: 140°; V:140° | H: 140°; V:140° | H: 140°; V:140° |
| Life Span | 100,000 hours | 100,000 hours | 100,000 hours | 100,000 hours |
| Working System | Windows | Windows | Windows | Windows |
Most models feature Kinglight LEDs and 3840Hz refresh rate. For additional pixel pitch options and technical details, please contact us.
Frequently Asked Questions
Q1: What is the control system? How is it?
A: We use Nova Taurus Series asynchronous control system. Support cluster play and management. Support APP/Phone/WIFI/iPad/Laptop/PC/Cloud control. It's very easy and convenient to control.
Q2: Can I have a sample order for LED screen?
A: Yes, we welcome sample orders to test and check quality. Mixed samples are acceptable.
Q3: Is it OK to print my logo on product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q4: What is your best service?
A:
1. One-to-one sales engineer to customer responsibility system
2. Know your project and provide the best solution for it
3. Track your order and let you know each step and detail
4. Teach you how to install and use the screen
5. Care for the subsequent use of your screen and ensure your after-sales service is well
Q5: How about your delivery time?
A: Generally, it will take 7-15 days after receiving your deposit. The specific delivery time depends on the items and the quantity of your order.
Q6: How about your Warranty Term?
A: 2-year warranty. Structure design, installation problem, system problem, how to use the screen - don't worry, we have professional after-sale team to solve your any questions after you placed an order. And your exclusive sales engineer will also help you get over any problems.
