Outdoor LED Display Screen with IP65 Waterproof Die Cast Aluminum Cabinet and 1920Hz-3840Hz Refresh Rate for Mobile Billboard
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | LEDKING or OEM & ODM |
| Model Number: | FO-P3 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | $750-790 |
|
Detail Information |
|||
| Pixel Pitch: | 3mm | Pixel Density: | 111111 Dot/m2 |
|---|---|---|---|
| Pixel Configuration: | 1R1G1B | Max Power Consumption: | 30W |
| Panel Weight: | 0.55KG | Cabinet Size: | 576mm*576mm*90mm,768*768*90MM |
| Cabinet Resolution: | 192 Dot * 192 Dot,256 Dot * 256 Dot | Quantity Of Panel: | 9pcs, 16pcs |
| Hub Connecting: | HUB75-E | Screen Power Supply: | AC110V/220V - 5V60A |
| Max Power Capacity: | 1100 W/m2 | Refresh Frequency: | 1920-3840 HZ/S |
| Brightness: | 4500-5000 Cd/m2 | Operating Temperature: | -10C°~45C° |
| IP Protective Index: | IP65 | ||
| Highlight: | IP65 Waterproof Outdoor LED Display Screen,1920Hz-3840Hz Refresh Rate LED Video Wall,Die Cast Aluminum Cabinet Mobile Billboard Display |
||
Product Description
Outdoor P3 Mobile Billboard Display Screen
High-resolution 1152×768×170mm waterproof IP65 outdoor LED screen panel designed for mobile billboard applications and video wall installations.
Product Specifications
Module Specifications
| Parameter | Outdoor P3 | Outdoor P3.91 | Outdoor P4 |
|---|---|---|---|
| Panel Dimension | 192mm(W) × 192mm(H) | 250mm(W) × 250mm(H) | 256mm(W) × 128mm(H) |
| Pixel Pitch | 3mm | 3.91mm | 4mm |
| Pixel Density | 111,111 dots/m² | 65,536 dots/m² | 62,500 dots/m² |
| Pixel Configuration | 1R1G1B | 1R1G1B | 1R1G1B |
| Specification | SMD1921 | SMD1921 | SMD1921 |
| Pixel Resolution | 64 × 64 dots | 64 × 64 dots | 64 × 32 dots |
| Max Power Consumption | 30W | 40W | 32W |
| Panel Weight | 0.55kg | 0.6kg | 0.3kg |
Cabinet Specifications
| Parameter | Outdoor P3 | Outdoor P3.91 | Outdoor P4 |
|---|---|---|---|
| Cabinet Size | 576×576×90mm, 768×768×90mm | 500×1000×90mm, 500×500×90mm | 1024×768×90mm |
| Cabinet Resolution | 192×192 dots, 256×256 dots | 128×256 dots, 128×128 dots | 256×192 dots |
| Quantity of Panels | 9pcs, 16pcs | 8pcs, 4pcs | 24pcs |
| Hub Connecting | HUB75-E | HUB75-E | HUB75-E |
| Cabinet Material | Die-casting aluminum | Die-casting aluminum | Die-casting aluminum |
| Maintenance Method | Front/Back service | Front/Back service | Front/Back service |
| Best Viewing Angle | 140°/120° | 170°/120° | 170°/120° |
| Screen Power Supply | AC110V/220V - 5V60A | AC110V/220V - 5V60A | AC110V/220V - 5V60A |
| Max Power Capacity | 1,100 W/m² | 1,200 W/m² | 1,550 W/m² |
| Average Power | 550 W/m² | 600 W/m² | 780 W/m² |
Technical Specifications
| Parameter | Outdoor P3 | Outdoor P3.91 | Outdoor P4 |
|---|---|---|---|
| Driving IC | ICN2037/2153 | ICN2037/2153 | ICN2037/2153 |
| Scan Rate | 1/16S | 1/16S | 1/8S |
| Refresh Frequency | 1920-3840 Hz/s | 1920-3840 Hz/s | 1920-3840 Hz/s |
| Display Color | 4096×4096×4096 | 4096×4096×4096 | 4096×4096×4096 |
| Brightness | 4500-5000 cd/m² | 4000 cd/m² | 5500-6000 cd/m² |
| Life Span | 100,000 hours | 100,000 hours | 100,000 hours |
| Control Distance | < 100m | < 100m | < 100m |
| Best Viewing Distance | 3-30m | 3-30m | 4-40m |
| Operating Temperature | -10°C to 45°C | -20°C to 60°C | -10°C to 45°C |
| Operating Humidity | 10-90% | 10-90% | 10-90% |
| IP Protective Index | IP65 | IP65 | IP65 |
Note: Most units feature Kinglight technology and 3840Hz refresh rate. For additional pixel pitch options and detailed technical specifications, please contact us.
