Outdoor LED Display Screen with Waterproof IP65 1920Hz-3840Hz Refresh Rate and Die Cast Aluminum Cabinet
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | LEDKING or OEM & ODM |
| Model Number: | FO-P3 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | $750-790 |
|
Detail Information |
|||
| Pixel Pitch: | 3mm | Pixel Density: | 111111 Dot/m2 |
|---|---|---|---|
| Pixel Configuration: | 1R1G1B | Max Power Consumption: | 30W |
| Panel Weight: | 0.55KG | Cabinet Size: | 576mm*576mm*90mm,768*768*90MM |
| Cabinet Resolution: | 192 Dot * 192 Dot,256 Dot * 256 Dot | Quantity Of Panel: | 9pcs, 16pcs |
| Hub Connecting: | HUB75-E | Best Viewing Angle: | 140/120 |
| Screen Power Supply: | AC110V/220V - 5V60A | Max Power Capacity: | 1100 W/m2 |
| Brightness: | 4500-5000 Cd/m2 | Control Distance: | < 100M |
| Operating Temperature: | -10C°~45C° | ||
| Highlight: | Waterproof IP65 Outdoor LED Display Screen,1920Hz-3840Hz Refresh Rate LED Video Wall Panel,Die Cast Aluminum Cabinet Mobile Billboard Display |
||
Product Description
Outdoor P3 Mobile Billboard Display Screen
High-performance outdoor LED video wall panel featuring waterproof IP65 rating and corner installation capability. Ideal for mobile billboard applications with dimensions 1152×768×170mm.
Product Specifications
Module Specifications
| Item | Outdoor P3 | Outdoor P3.91 | Outdoor P4 |
|---|---|---|---|
| Panel Dimension | 192mm(W) × 192mm(H) | 250mm(W) × 250mm(H) | 256mm(W) × 128mm(H) |
| Pixel Pitch | 3mm | 3.91mm | 4mm |
| Pixel Density | 111111 dot/m² | 65536 dot/m² | 62500 dot/m² |
| Pixel Configuration | 1R1G1B | 1R1G1B | 1R1G1B |
| Specification | SMD1921 | SMD1921 | SMD1921 |
| Pixel Resolution | 64 dot × 64 dot | 64 dot × 64 dot | 64 dot × 32 dot |
| Max Power Consumption | 30W | 40W | 32W |
| Panel Weight | 0.55KG | 0.6KG | 0.3KG |
Cabinet Specifications
| Item | Outdoor P3 | Outdoor P3.91 | Outdoor P4 |
|---|---|---|---|
| Cabinet Size | 576mm×576mm×90mm, 768×768×90MM | 500×1000mm×90mm, 500×500×90mm | 1024mm×768mm×90mm |
| Cabinet Resolution | 192 dot × 192 dot, 256 dot × 256 dot | 128 dot × 256 dot, 128×128 dot | 256 dot × 192 dot |
| Quantity of Panel | 9pcs, 16pcs | 8pcs, 4pcs | 24pcs |
| Hub Connecting | HUB75-E | HUB75-E | HUB75-E |
| Cabinet Material | Die-casting aluminum cabinet | Die-casting aluminum cabinet | Die-casting aluminum cabinet |
| Maintenance Method | Front/Back service | Front/Back service | Front/Back service |
| Best Viewing Angle | 140°/120° | 170°/120° | 170°/120° |
| Screen Power Supply | AC110V/220V - 5V60A | AC110V/220V - 5V60A | AC110V/220V - 5V60A |
| Max Power Capacity | 1100 W/m² | 1200 W/m² | 1550 W/m² |
| Average Power | 550 W/m² | 600 W/m² | 780 W/m² |
Technical Specifications
| Item | Outdoor P3 | Outdoor P3.91 | Outdoor P4 |
|---|---|---|---|
| Driving IC | ICN 2037 / 2153 | ICN 2037 / 2153 | ICN 2037 / 2153 |
| Scan Rate | 1/16S | 1/16S | 1/8S |
| Refresh Frequency | 1920-3840 HZ/S | 1920-3840 HZ/S | 1920-3840 HZ/S |
| Display Color | 4096×4096×4096 | 4096×4096×4096 | 4096×4096×4096 |
| Brightness | 4500-5000 cd/m² | 4000 cd/m² | 5500-6000 cd/m² |
| Life Span | 100,000 Hours | 100,000 Hours | 100,000 Hours |
| Control Distance | < 100M | < 100M | < 100M |
| Best Viewing Distance | 3-30M | 3-30M | 4-40M |
| Operating Temperature | -10°C to 45°C | -20°C to 60°C | -10°C to 45°C |
| Operating Humidity | 10-90% | 10-90% | 10-90% |
| IP Protective Index | IP65 | IP65 | IP65 |
Most units feature Kinglight technology and 3840Hz refresh rate. For custom specifications, additional pixel pitch options, and detailed technical requirements, please contact our sales team.
Manufacturer Profile
Professional manufacturer specializing in high-quality outdoor LED display solutions with extensive experience in mobile billboard and video wall applications.
