IP65 Outdoor P4 P5 High Brightness LED Video Wall Display Screen Fixed LED Panel for Shopping Center Sports Event Display
Product Details
| Control System: | NOVA Star | Life Span: | 100000Hours |
|---|---|---|---|
| IC: | Chipone ICN2153 | Cabinet Material: | Waterproof Iron |
| Panel Weight: | 40kg | Power Supply: | AC110V/220V-5V60A |
| Highlight |
IP65 waterproof LED display screen,P4 P5 high brightness LED panel,outdoor fixed LED video wall |
||
Product Description
| Module Specifications | |
|---|---|
| Module Size | 320mm(W) × 160mm(H) |
| Pixel Pitch | 4mm / 5mm |
| Pixel Density | 62,500 dots/㎡ (4mm) / 40,000 dots/㎡ (5mm) |
| Pixel Configuration | 1R1G1B |
| LED Specification | SMD1921 |
| Pixel Resolution | 80 × 40 dots (4mm) / 64 × 32 dots (5mm) |
| Max Power Consumption | 45W |
| Panel Weight | 0.5KG |
| Cabinet Specifications | |
|---|---|
| Cabinet Size | 960 × 960mm |
| Cabinet Resolution | 240 × 240 dots (4mm) / 192 × 192 dots (5mm) |
| Quantity of Panel | 18pcs |
| Hub Connecting | HUB75-E |
| Material | Waterproof Iron cabinet |
| Maintenance Method | Front/Back service |
| Best Viewing Angle | 170°/120° |
| Power Supply | AC110V/220V-5V60A |
| Max Power Consumption | 1300W/㎡ |
| Average power consumption | 650W/m² |
| Technical Signal Index | |
|---|---|
| Driving IC | ICN2153 |
| Scan Rate | 1/10S / 1/8S |
| Refresh Frequency | 3840-7680HZ/S |
| Display Color | 4096 × 4096 × 4096 (16bit) |
| Contrast Ratio | 4000:1 |
| Brightness | 4500-5500 cd/㎡ |
| Life Span | 100,000 Hours |
| Best Viewing Distance | 4-40M |
| Operating Temperature | -20℃ ~ 60℃ |
| Operating Humidity | 10-90% |
| IP Protective Index | IP65 |
- Ultra-high definition display: Exquisite and lifelike image quality maintains clarity even at close range, perfect for detailed advertising content.
- High brightness performance: Maintains excellent visibility in direct sunlight and strong light environments.
- Rugged outdoor protection: IP65 rating withstands harsh weather including sun, rain, and sandstorms.
- Energy efficient operation: Low power consumption and heat generation with extended lifespan reduces maintenance costs.
- Vibrant color reproduction: Rich, realistic colors with smooth dynamic images for maximum visual impact.
- Commercial real estate: Brand image walls and high-end advertising displays.
- Digital billboards: High-visibility advertising in commercial districts.
- Cultural/sports events: Stage displays and live streaming with excellent color reproduction.
- Hotels/convention centers: Information displays and directional signage.
- Transportation hubs: Flight information and public service displays.
- Financial institutions: Corporate signage and financial data displays.
